Factory Lead Time

9 Weeks

Mounting Type

Through Hole

Package / Case

24-DIP Module, 8 Leads

Number of Pins

8

Weight

13g

Voltage - Input (Nom)

24V

Power Dissipation (Max)

5W

Operating Temperature

-40°C~75°C

Packaging

Tube

Series

ECONOLINE REC5 (5W)

Size / Dimension

1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

9

ECCN Code

EAR99

Type

Isolated Module

Applications

ITE (Commercial)

Terminal Position

DUAL

Terminal Form

PIN/PEG

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Terminal Pitch

2.54mm

Depth

20.3mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

JESD-30 Code

R-PDMA-P9

Number of Outputs

1

Qualification Status

Not Qualified

Efficiency

77%

Voltage - Isolation

2kV

Voltage - Input (Max)

36V

Voltage - Input (Min)

18V

Trim/Adjustable Output

NO

Current - Output (Max)

1A

Current - Output

1A

Output Power

5W

Max Output Voltage

3.3V

Voltage - Output

3.3V

Total Power Output-Max

3.3W

Nominal Input Voltage

24V

Isolation

Isolated

Features

SCP

Height

10.2mm

Length

32mm

RoHS Status

ROHS3 Compliant

Lead Free

Lead Free
